Customized Electric Car Charging station 7kW 1Phase APP Android and iOS Systems 6.1m Cable 32A Wallbox EV Charger

Business AC Charger

Products Categories
Featured Products
IP66 Waterproof EV CHARGER 3 phase 16A 11kW type 2 Floor-mounted Charging Stations for electric vehicles

IP66 Waterproof EV CHARGER 3 phase 16A 11kW type 2 Floor-mounted Charging Stations for electric vehicles
32A 7kW Electric Car Charger EV Charging Pile with Type 2 Plug

32A 7kW Electric Car Charger EV Charging Pile with Type 2 Plug
10kw Ev Charger Wall-Mounted Charging Stations 9.6kw Home Commercial Type1 Type2 Gbt Ev Ac Charger Yiwu(F30)

10kw Ev Charger Wall-Mounted Charging Stations 9.6kw Home Commercial Type1 Type2 Gbt Ev Ac Charger Yiwu(F30)
Level 2 40Amp ev charger Station 9.6KW NEMA14-50 Wall Electric Vehicle Charging Station for Electric and Hybrid Vehicles

Level 2 40Amp ev charger Station 9.6KW NEMA14-50 Wall Electric Vehicle Charging Station for Electric and Hybrid Vehicles
Wallbox e v charging stations 7kw 6.6kw ev on board charger home chademo charger with CE ROHS

Wallbox e v charging stations 7kw 6.6kw ev on board charger home chademo charger with CE ROHS
Home Charger for Tesla 9.6kw Charger Wallbox AC EV Fast Charging Station 7.2kw Ev Charging Products(F30)

Home Charger for Tesla 9.6kw Charger Wallbox AC EV Fast Charging Station 7.2kw Ev Charging Products(F30)
9.6KW Anti-Theft Wall-Mounted Charging Station Electric Golf Cart Charging Station 220v 40A(F30)

9.6KW Anti-Theft Wall-Mounted Charging Station Electric Golf Cart Charging Station 220v 40A(F30)
Clean Energy EV Car Charger Station 22kW 32A APP Smartphone Android and iOS System EV Charger with Type 2 Cable

Clean Energy EV Car Charger Station 22kW 32A APP Smartphone Android and iOS System EV Charger with Type 2 Cable
OEM 9.6kW Electric Car Charger Station ETL APP Wifi Remote Control CE RoHS 40A EV Wallbox Charger with 20 Feet Cable

OEM 9.6kW Electric Car Charger Station ETL APP Wifi Remote Control CE RoHS 40A EV Wallbox Charger with 20 Feet Cable
9.6kW EV Wallbox 40A American Standard 6.1 Meters Charging Cable Electric Vehicle Charger Station

9.6kW EV Wallbox 40A American Standard 6.1 Meters Charging Cable Electric Vehicle Charger Station
01

Customized Electric Car Charging station 7kW 1Phase APP Android and iOS Systems 6.1m Cable 32A Wallbox EV Charger

  • Place of Origin Guangdong, China
  • Output Current AC
  • Output Power 7kW
  • Input Voltage 200 - 240v
  • Purpose for retrofit/upgrade
  • Condition New
  • Model Number BS20-BC-7kW-APP-6.1m-NonA+6
  • Certificate ETL
  • IP Grade 66
  • Color Black or Customization
  • Operating Current, Voltage 32A, 220V
  • Cable Length 6.1 meters
  • Working Place Indoor / Outdoor
  • Control Auto/Button/Key/Card
  • Key Words electric charging station for electric car
  • Car Fitment Adapted all Models
Contact us

PRODUCT SPECIFICATION

Product Name

EV Charging Station

Model

BS20-BC-7kW-APP-6.1m-NonA+6

Rated Voltage

200 - 240v

Rated Current

32A

Output Power

7KW

description2

Products Description

IMG_3421

Smart Charging BS20 Series
The BS20 is Product classic wallbox product, designed to comply with North American standard SAE J1772 (Type 1), European standard IEC 62196-2 (Type 2), and Chinese standard GB/T, offering a maximum output power of 22kW. It is equipped with an LED charging status indicator, a 3.5-inch LCD charging display, and a button switch, along with a built-in Type A 30mA AC+6mA DC leakage protector to ensure user safety.

The durable housing design is suitable for long-term use and is suitable for both wall and floor-mounted installation. Additionally, it has an IP66 protection rating, ensuring it is waterproof and dustproof for reliable outdoor use

He5f86b921b72427e99d11b9f3d55a00ax

Hab6f5126143c4d369588be03f2176ea6B

Model
BS20-Mode A
BS20-Mode C
Optional Series
Basic,APP,RFID,OCPP,Load Balance
AC Power Output Rating
Max 22kW
AC Power Input Rating
AC 110V~400V
Current Output
Max 40A Single Phase/32A Three Phase
Required Service Panel Breaker
Dedicated Dual Pole rated for 125% of maximum load (ex: 40A breaker for 32A output)
Power Wiring
3 Wires–L1, PE, N / 5 Wires–L1, L2, L3, PE, N
Connector Type
TYPE 2(IEC 62196-2)
GB/T
TYPE 1(SAE J1772)
TYPE 2(IEC 62196-2)
GB/T
Charging Cable
TPU
TPU 6.1m(20ft)
EMC Compliance
EN IEC 61851-21-2: 2021
Ground Fault Detection
20 mA CCID with auto retry
Ingress Protection
IP66,IK10
Electrical Protection
Over current protection
Short circuit protection
Under voltage protection
Leakage protection
Over temperature protection
Lightning protection
RCD type
TypeA AC 30mA + DC 6mA
Operating Temperature
-25℃ ~+55℃
Operating Humidity
0-95% non-condensing
Certifications
CE/FCC/CSA/RoHS/ETL
Mounting Method
Wall-Mounted/Floor-Mounted
Optional Series
Ethernet/WIFI/4G/Bluetooth
Timing and Delay
12H(Real-time display of charging status)
LCD Display
3.5-inch Color Display
LED Indicator Light
Yes
Button On/OFF
Yes
External Package
Customizable/Eco-Friendly Cartons
Package Dimension
680*250*140mm
Gross Weight
5KG~8.5KG
